Schneider Electric APC Performance SurgeArrest 6 outlets with 5V, 2.4A 2 port USB charger PM6U-GR

Description for Schneider Electric APC Performance SurgeArrest 6 outlets with 5V, 2.4A 2 port USB charger PM6U-GR

Schneider Electric APC Performance SurgeArrest 6 outlets with 5V, 2.4A 2 port USB charger PM6U-GR

Description
This product is part of the SurgeArrest Essential family. It features six surge protected outlet with a rating of 1836 Joules. The PM6U-GR also has 2 USB ports to simultaneously charge your mobile devices. It also features EMI and RFI filtering, protecting against data errors and keyboard issues due to electrical interference. Its dimensions are 6.2 x 27.2 x 11 cm and 0.75 kg. The APC SurgeArrest Essential series represents the primary level of surge protection that should be present on any of your computers and household electronics.

Specifications

---

Overview

Lead time	Usually in Stock

Main

Main Input Voltage	230 V
Input Connection Type	Schuko CEE 7/7P
cable length	2.00 m
number of cables	1
provided equipment	User manual

Physical

colour	White
height	6.2 cm
width	27.2 cm
depth	11 cm
net weight	0.75 kg
mounting preference	No preference
mounting mode	Rack-mounted

Input

input power	2300 W
network frequency	50 Hz
maximum input current	10 A
switching current capacity	10 A

Output

number of power socket outlets	6
outlet standard	Schuko CEE 7

Conformance

product certifications	CE
equipment protection policy	Lifetime : 50000 euros

Environmental

ambient air temperature for operation	0…40 °C
relative humidity	0…95 % non-condensing
operating altitude	0...50000 ft
ambient air temperature for storage	-15…45 °C
storage Relative Humidity	0…95 %
storage altitude	0.00…15240.00 m

Surge Protection and Filtering

response time	1 ns common mode
Common mode rejection	40 dB
peak current	48 kA common mode
Surge energy rate	1836 J

Packing Units

Package 1 Weight	0.89 kg
Package 1 Height	6.5 cm
Package 1 width	31 cm
Package 1 Length	16.5 cm
SCC14	10731304313721
Number of Units in Package 2	12
Package 2 Weight	10.68 kg
Package 2 Height	406.40 mm
Package 2 width	330.20 mm
Package 2 Length	355.60 mm
Number of Units in Package 3	96

Contractual warranty

Warranty	Limited Lifetime (European Union countries only)

REACh Regulation

REACh Declaration

EU RoHS Directive

Compliant

EU RoHS Declaration

Environmental Disclosure

Product Environmental Profile

WEEE

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Circularity Profile

End of Life Information
