Schneider Electric Easypact CVS CVS100F circuit breaker 3P/3d LV510805

Schneider Electric Easypact CVS CVS100F circuit breaker 3P/3d
Model :LV510805
SKU :LV510805
Assured Free Delivery

No Return 7 days retun policy available
Cash on Delivery Cash on Delivery available
AED 183.00
Rate inclusive of VAT
Sold By : MEPKart
Fulfilled by Thomsun Industries

100%
- +
Bulk Order

  •  Condition: New

Description for Schneider Electric Easypact CVS CVS100F circuit breaker 3P/3d LV510805


Schneider Electric Easypact CVS CVS100F circuit breaker 3P/3d LV510805


Specifications


Main
RangeEasyPact
Product nameEasyPact CVS
Device short nameCVS100F
Product or component typeCircuit breaker
Device applicationDistribution
Poles description3P
Protected poles description3D
Earth leakage protection (Vigi add on)Without
[In] rated current40 A
Network typeAC
Utilisation categoryCategory A
[Icu] Breaking capacity36 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
70 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
Trip unit nameTM-D
Trip unit technologyThermal-magnetic
Trip unit rating40 A at 40 °C
Protection typeOverload protection (thermal)
Short-circuit protection (magnetic)

Complementary
[Uimp] rated impulse withstand voltage8 kV conforming to EN/IEC 60947-2
Network frequency50/60 Hz
Breaking capacity codeF
[Ics] rated service breaking capacity18 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
36 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
70 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
Mechanical durability30000 cycles
Electrical durability12000 cycles 415 V In conforming to IEC 60947-2
Control typeToggle
Long time pick-up adjustment type IrAdjustable
long time pick-up adjustment range0.7...1 x In
long time delay adjustment typeFixed
Short-time delay adjustment typeFixed
Instantaneous pick-up adjustment type IiFixed
Instantaneous pick-up adjustment range500 A
Contact position indicatorYes
Mounting modeFixed
Mounting supportBackplate
upside connectionFront
Downside connectionFront
Connection pitch35 mm
Compatibility codeCVS100
Width105 mm
Depth86 mm
Height161 mm

Environment
StandardsIEC 60947-2
EN 60947-2
Product certificationsGOST
IEC
Electrical shock protection classClass II
Ambient air temperature for operation-25…70 °C
Ambient air temperature for storage-50…85 °C
